Aluzinc Galvalume Color Coated Coils for Long-Term Protection

(6 Reviews)

Galvalume color coated coil
author: supereditor
OVERVIEW:

Galvalume Color Coated Coil – Durable, Versatile, and High-Performance Steel for All Your NeedsOverview:Galvalume Color Coated Coil is an advanced material used in a wide range of industrial and architectural applications. Combining the durability of a steel core with the protective and aesthetic p

tags:

Galvalume Color Coated Coil, PPGL Coil

Galvalume Color Coated Coil – Durable, Versatile, and High-Performance Steel for All Your Needs


Overview:

Galvalume Color Coated Coil is an advanced material used in a wide range of industrial and architectural applications. Combining the durability of a steel core with the protective and aesthetic properties of a color-coated finish, Galvalume coils are highly resistant to corrosion, rust, and wear. The versatile combination of steel, aluminum, and zinc coatings ensures long-lasting performance, making it an ideal choice for building facades, roofing, and other exterior applications.

Key Features:

Superior Corrosion Resistance: Galvalume coils feature a blend of aluminum and zinc coatings, offering exceptional resistance to harsh environmental conditions. Ideal for coastal, industrial, and urban areas where corrosion resistance is critical.

Long-Lasting Performance: The steel substrate is coated with a layer of aluminum and zinc, providing a highly durable finish that extends the lifespan of the material. The color-coated surface adds an extra layer of protection and beauty.

Customizable Color Options: Available in a wide range of vibrant and durable color finishes, Galvalume color coated coils can be customized to meet specific aesthetic needs for residential, commercial, and industrial buildings.

Energy Efficiency: The reflective properties of the color-coated surface help reduce the absorption of heat, contributing to improved energy efficiency, especially in roofing applications.

Eco-Friendly: Galvalume is a recyclable material, making it an environmentally responsible choice for construction and manufacturing.



Product Specifications

Specification

Details

Material Composition

Steel core with 55% Aluminum, 43.4% Zinc, and 1.6% Silicon alloy coating

Coating Thickness

Typically ranges from 0.3mm to 0.7mm (custom thickness available upon request)

Coil Width

600mm to 1250mm (custom widths available depending on requirements)

Coil Length

Standard: 1.0m to 8.0m (custom lengths available based on client needs)

Thickness of Steel Substrate

0.2mm to 1.5mm (custom options available for various applications)

Color Options

RAL color standard or custom color matching available

Surface Finish

Smooth, matte, or textured finish (choose based on aesthetic and performance needs)

Tensile Strength

280 MPa – 550 MPa (customized options for high-strength applications)

Yield Strength

150 MPa – 450 MPa (dependent on substrate thickness)

Coating Weight

50g/m² to 275g/m² (higher coating weight for superior corrosion protection)

Surface Treatment

Pre-painted with polyester, PVDF, or other coatings for additional protection and color stability

Corrosion Resistance

Excellent resistance in highly corrosive environments (including coastal areas)

Gloss Level

Low Gloss (10-30%), Medium Gloss (30-50%), High Gloss (50-90%) (choose based on design requirements)

Thermal Reflectivity

Reflective coatings available, improving energy efficiency and UV resistance

Impact Resistance

High impact resistance for areas with high traffic or heavy environmental stress

Applications

Roofing, wall cladding, garage doors, household appliances, automotive parts, HVAC ducts

Color Coating Material

Available in Polyester, Siliconized Polyester, PVDF, or SMP for different applications and performance levels

Bending Radius

Recommended minimum bending radius: 1.5 times the coil thickness (for optimal performance)

Packaging

Coils are packaged in strong, moisture-resistant wrapping to ensure safe delivery







Customization Options:

Custom Length & Width: Galvalume coils can be manufactured to meet your exact project specifications. Whether you need coils for large-scale commercial buildings or small residential projects, we can adjust the dimensions to fit your needs.

Coating Type: Choose from a variety of coating options including Polyester, Polyvinylidene Fluoride (PVDF), or Silicone Modified Polyester (SMP) to suit your performance and aesthetic requirements.

Color Matching: We provide custom color matching services to ensure the exact hue you need, helping to meet your specific design and branding standards.

By offering a wide range of specifications and customization options, Galvalume Color Coated Coils can be tailored to your unique project requirements, whether you're looking for an aesthetically appealing solution or a high-performance material that can withstand harsh environmental conditions.



Advantages of Galvalume Color Coated Coil:

Enhanced Durability: The unique aluminum-zinc coating prevents rust and corrosion, significantly extending the service life of the material compared to regular galvanized steel.

Variety of Color Finishes: Choose from an array of color options that provide both visual appeal and superior weather resistance.

Cost-Effective: Offers a long-lasting, low-maintenance solution that can lower lifecycle costs for construction and industrial projects.

Strong and Lightweight: Galvalume coils are lightweight but provide high tensile strength, making them easy to handle while maintaining structural integrity.

Weather Resistance: The coating helps protect against extreme temperatures, humidity, and UV exposure, making it a great choice for outdoor applications.



Applications:

Galvalume Color Coated Coils are versatile and can be used in many industries, including construction, automotive, and manufacturing. Some of the most common applications include:

Building Facades & Roofing: Protects buildings against the elements while enhancing the appearance with a variety of color finishes.

Garage Doors & Shutters: Provides strong, long-lasting protection for doors and shutters.

Air Conditioning and Ductwork: Resists corrosion from exposure to air and water, ensuring longevity and reliability in HVAC systems.

Home Appliances: Used for the outer casing of washing machines, refrigerators, and other household appliances, offering both protection and aesthetic appeal.



Why Choose Galvalume Color Coated Coil?

Reliable Performance: Whether you are constructing a commercial building or manufacturing automotive parts, Galvalume color coated coils provide exceptional performance in challenging conditions.

Long-Term Investment: With superior durability and minimal maintenance requirements, Galvalume coils offer excellent value for your investment.

Sustainability: Galvalume’s recyclable properties and reduced energy consumption contribute to sustainable practices and greener projects.



Conclusion:

Galvalume Color Coated Coils are an ideal solution for a range of applications, combining beauty, durability, and performance. Whether you’re building a new home, upgrading a commercial facility, or manufacturing high-quality products, Galvalume provides the strength and longevity you need. Invest in Galvalume Color Coated Coils today for a cost-effective, environmentally friendly, and highly durable material solution.

For inquiries, samples, or more detailed product specifications, contact us today!
